4" Caster Wheel - PVC - Top Plate Mount

4" Inch Caster Wheel 198 pounds Swivel Polyvinyl Chloride Top Plate

VXB004100PVC

Medium Duty

Wheel Diameter= 100mm

Wheel Width= 30mm

Wheel Diameter= 4" Inch = 100mm

Overall Height= 130mm

Overall Height Inch= 5.118"

Mounting Type= Top Plate

Top Plate Size= 93mm x 62mm

Hole distance= 73mm x 45mm

Wheel Core= Polyvinyl Chloride

Tire= Polyvinyl Chloride

Bearing type= Double ball bearing

Load Capacity= 198 lb

Mounting= Swivel

Temperature Range= -40 to 180 F

Heavy weight capability and Durability made the wheel casters like the VXB004100PVC a must use, get your do it yourself object move around. Diameter size of the caster wheel has a metric standard 100mm which is equal to 3.937" inch with imperial units. The wheel has a width of 30mm=1.181" inch. The caster dimensions heightwise is 130mm/5.118" inch. Mounted via a Top Plate that has the size of 93mm x 62mm and the holes distance of 73mm x 45mm. The weehl core material is Polyvinyl Chloride and has a Polyvinyl Chloride tire with a low friction Double ball bearing. Each caster will carry the load of 198 lb and is Swivel type. Temperature range is -40 to 180 F. Buy the VXB004100PVC now, just add the quantity to basket and click on Checkout.
