5" Heavy Duty Caster Wheel 507 Lbs Fixed - TPR - Top Plate Mount

5" Inch Caster Wheel 507 pounds Fixed Thermoplastic Rubber Top Plate

VXB005125BTPRB1

Heavy Duty

Wheel Diameter= 125mm

Wheel Width= 50mm

Wheel Diameter= 5" Inch = 125mm

Overall Height= 166mm

Overall Height Inch= 6.535"

Mounting Type= Top Plate

Top Plate Size= 100mm x 115mm

Hole distance= 75mm x 85mm

Wheel Core= Thermoplastic Rubber

Tire= Thermoplastic Rubber

Bearing type= Double ball beaing

Load Capacity= 507 lb

Mounting= Fixed

Temperature Range= -40 to 180 F

Moves large items quicker using the VXB005125BTPRB1. The wheel diameter is 125mm or 4.921" inch in inches. The wheel has a width of 50mm=1.969" inch. The caster dimensions heightwise is 166mm/6.535" inch. Mounted via a Top Plate that has the size of 100mm x 115mm and the holes distance of 75mm x 85mm. The Double ball beaing design will enable the Thermoplastic Rubber tire to roll easily with a core made from Thermoplastic Rubber. Bearing in mind that every caster wheel has the load capacity of 507 lb with a Fixed type. Environment temperature range is -40 to 180 F. Buy the VXB005125BTPRB1 now, just add the quantity to basket and click on Checkout.
