• 5211 Nachi 2 Rows Angular Contact Bearing 55x100x33.3 Japan Bearings - VXB Ball Bearings
1 3

Nachi

5211 Nachi Angular Contact Bearing - 2-Row - 55x100x33.3 Japan Made

5211 Nachi Angular Contact Bearing - 2-Row - 55x100x33.3 Japan Made

$124.46 USD
$138.46 USD $124.46 USD
Sale Sold out
Shipping calculated at checkout.
5211 Nachi Double Row Angular Ball Bearing
55mm x 100mm x 33.3mm
Made in Japan

5211 Nachi Double Row Angular Ball Bearing, Made in Japan, inner diameter is 55mm, outer diameter is 100mm and width is 33.3mm.

  • 5211 Ball Bearing
  • Nachi Double Row Angular Ball Bearing
  • Closures: Open
  • Dimensions: 55mm x 100mm x 33.3mm/Metric
  • ID (inner diameter)/Bore: 55mm
  • OD (outer diameter): 100mm
  • Width: 33.3mm
  • Size: 55 x 100 x 33.3 mm
  • Quantity: 1 Bearing
  • Dynamic load rating Cr: 67,500 N
  • Static load rating Cor: 56,500 N
  • Limiting Speed:
    • Grease Lubrication: 4,500 RPM
    • Oil Lubrication: 6,300 RPM
  • Made in Japan

The construction of this type ball bearing is similar to the adjacent, BACK-TO-BACK mounting of two Single-row Angular Contact ball bearings. Because fewer balls can be inserted per row compared to Single-row Angular Contact ball bearings, a Double-row Angular Contact ball bearing will have less load capacity than an equivalent size/series BACK-TO-BACK set of two Single-row Angular Contact ball bearings. This bearing type can sustain radial, moment and bi-directional axial loads.
