5217 Nachi Angular Contact Bearing - 2-Row - Japan 85x150x49.2 Bearing

5217 Nachi Angular Contact Bearing - 2-Row - Japan 85x150x49.2 Bearing

Regular price $426.08 USD
Regular price $474.00 USD Sale price $426.08 USD
Sale Sold out
Shipping calculated at checkout.
5217 Nachi Angular Ball Bearing
85mm x 150mm x 49.2mm
Made in Japan


5217 Nachi Double Row Angular Ball Bearing, Made in Japan, inner diameter is 85mm, outer diameter is 150mm and width is 49.2mm.

  • 5217 Nachi Ball Bearing
  • Nachi Double Row Angular Ball Bearing
  • Closures: Open
  • Dimensions: 85mm x 150mm x 49.2mm/Metric
  • ID (inner diameter)/Bore: 85mm
  • OD (outer diameter): 150mm
  • Width: 49.2mm
  • Size: 85 x 150 x 49.2 mm
  • Quantity: 1 Bearing
  • Dynamic load rating Cr: 112,000 N
  • Static load rating Cor: 103,000 N
  • Limiting Speed:
    • Grease Lubrication: 3,000 RPM
    • Oil Lubrication: 4,000 RPM
  • Made in Japan

The construction of this type ball bearing is similar to the adjacent, BACK-TO-BACK mounting of two Single-row Angular Contact ball bearings. Because fewer balls can be inserted per row compared to Single-row Angular Contact ball bearings, a Double-row Angular Contact ball bearing will have less load capacity than an equivalent size/series BACK-TO-BACK set of two Single-row Angular Contact ball bearings. This bearing type can sustain radial, moment and bi-directional axial loads.
