Nachi

5313ZZ Nachi Angular Contact Bearing - 2-Row - 65x140x58.7 Bearing

5313ZZ Nachi Angular Contact Bearing - 2-Row - 65x140x58.7 Bearing

$587.88 USD
$654.00 USD $587.88 USD
Sale Sold out
Shipping calculated at checkout.
5313ZZ Nachi Angular Ball Bearing
65mm x 140mm x 58.7mm
Double Shielded
Made in Japan

5313ZZ Nachi Double Row Angular Ball Bearing, bearing is Double Shielded, Made in Japan. inner diameter is 65mm, outer diameter is 140mm and width is 58.7mm.

  • 5313ZZ Ball Bearing
  • Nachi Double Row Angular Ball Bearing
  • Closures: Double Shielded
  • Dimensions: 65mm x 140mm x 58.7mm/Metric
  • ID (inner diameter)/Bore: 65mm
  • OD (outer diameter): 140mm
  • Width: 58.7mm
  • Size: 65 x 140 x 58.7 mm
  • Quantity: 1 Bearing
  • Dynamic load rating Cr: 145,000 N
  • Static load rating Cor: 115,000 N
  • Limiting Speed:
    • Grease Lubrication: 3,600 RPM
  • Made in Japan

The construction of this type ball bearing is similar to the adjacent, BACK-TO-BACK mounting of two Single-row Angular Contact ball bearings. Because fewer balls can be inserted per row compared to Single-row Angular Contact ball bearings, a Double-row Angular Contact ball bearing will have less load capacity than an equivalent size/series BACK-TO-BACK set of two Single-row Angular Contact ball bearings. This bearing type can sustain radial, moment and bi-directional axial loads.
