6906DU Bearing - Sealed Ball Bearing 30x47x9mm
6906DU Bearing - Sealed Ball Bearing 30x47x9mm
Couldn't load pickup availability
6906DU Sealed Ball Bearing
✨ 30mm x 47mm x 9mm - Rubber Sealed, Greased Chrome Steel
The 6906DU Bearing is a deep groove ball bearing built with chrome steel and sealed with rubber on both sides for clean, maintenance-free operation. It’s a slim-profile bearing, perfect for high-speed applications like electric motors, hubs, and precision assemblies where space is limited and protection from dust matters.
🟢 Size: 30mm ID x 47mm OD x 9mm width
🟢 Material: Chrome steel inner, outer, and cage
🟢 Rubber sealed on both sides (DU) to block contaminants
🟢 Pre-lubricated with grease for smooth operation
🟢 Dynamic load rating: 7,250 N
🟢 Static load rating: 5,000 N
🟢 Grease-lubed speed limit: 8,200 RPM
🟢 Quantity: One bearing
Dimension Table (mm):
| Inner Diameter | Outer Diameter | Width | Cr (N) | Cor (N) | Max RPM |
|---|---|---|---|---|---|
| 30mm | 47mm | 9mm | 7,250 | 5,000 | 8,200 |
☑️ Equivalent Bearing:
-
61906-2RS1
